Burndy Compression Terminal, 1 AWG, Copper, 1 Hole, 1/2" Stud, Long Barrel
Part #1428673
MFG #YA1CN
$ / EA
1 AWG CU, One Hole, 1/2 Stud Size, Long Barrel, Internal Chamfer, Tin Plated, UL/CSA, 90°C, Up to 35kV,GREEN Color Code, 11 or 375 Die Index.
FEATURES:
FEATURES:
- Barrel designed with internal chamfer at wire entry for smooth insertion of wire, preventing possible damage of the strands
- Long barrel length allows for an increased number of crimps increasing the mechanical strength of the connection
- Electro-tin plated unless otherwise specified to reduce galvanic corrosion (bimetallic) and resist corrosive elements
- Connectors are clearly marked with stamping and barrel color coding
- Brand: BurndySystem of Measurement: Unified (inch)Material: CopperFinish: TinColor: GreenMil-Spec: NoRoHS Compliant: Yes
- 8536.90.4000
